Hardware |
|
Core board |
|
WM6.1/6.5 OS |
option1 |
Marvell PXA310(806MHz)+qualcomm (GSM band 900/1800/1900MHz, GPRS, EDGE/WCDMA 2100MHz HSDPA 3.6Mbps |
|
WM6.1/6.5 OS |
option2 |
Marvell PXA310(806MHz)+qualcomm EVDO (800MHz, CDMA 1X, EVDO) |
|
android 2.3 OS |
YES |
Marvell PXA910(806MHZ) +GSM Quad-band 850/900/1800/1900MHz, GPRS, EDGE/ WCDMA900/1700/2100MHz HSDPA 3.6Mbps |
|
Memory |
Flash ROM |
512MB |
|
RAM |
512MB DDR |
|
Extend Slot |
Micro SD 16G (SDHC) |
|
Motherboard |
|
Display |
3.5inch TFT LCD display (320 x 240) 65k color/touch panel/Transflective screen |
|
Form Factor |
Bar type classical Pocket PC,Industrial appearance |
|
GPS Solution |
Ublox The 5th Generation |
|
Wire Transmission |
USB 2.0 Full Speed, charging/sync |
|
Bluetooth |
Bluetooth SIG version 2.0 compliant; Supported profiles: headset, hands-free, object push, serial port, dial-up network |
|
WiFi |
WiFi (802.11 b/g) |
|
RFID |
option 1 |
HF RFID RF30 (ISO 14443A/B) |
|
option 2 |
HF RFID RF60 (ISO 14443A/B ISO 15693) |
|
option 3 |
LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX) |
|
option 4 |
LF RFID(125khz) |
|
option 5 |
UHF RFIDams AS3992: ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode) |
|
Barcode Scanner |
option 1 |
1D Infrared scanner (NewLand:EM1300) |
|
YES |
1D Laser scanner (Symbol:SE9551) |
|
option 3 |
1D Laser scanner (Honey:N4313) |
|
option4 |
2D Barcode scanner (SE4500SR) |
|
GPS |
option 1 |
UBLOX LEA-6S |
|
option 2 |
UBLOX LEA-6T |
|
option 3 |
UBLOX LEA-6N |
|
C-MOS imager |
5M AF |
|
External Interface |
USB HOST/RS232/SPI/IIC |
|
Protection class |
IP65 |
|
Drop resistance level |
1.5m |
|
Audio |
Handfree |
Yes |
|
StereoBlueTooth earphone |
Yes |
|
Ringtone |
support 64-chord MIDI, MP3, WMA, WAV |
|
Playback |
support MIDI, MP3, WMA, WAV, AMR |
|
Speaker |
support handfree |
|
Network Led |
red/green/yellow |
|
Keypad |
Front |
Number key, Function key |
|
Side |
Volume up, Volume down,camera |
|
Interface |
Mini-USB connector |
USB2.0 connection and power charging |
|
SIM card slot |
Yes |
|
Audio Jack |
YES |
|
Battery |
Type |
rechargeable Li-ion battery 4500mAh |
|
Standby Time |
500hours |
|
Calls Time |
Up to 6hours |
|
Charging Time |
4 hours |
|
Physical Characteristics |
Dimension |
182*82*36mm |
|
Weight |
>400g with battery (according config) |
|
Key Software |
|
Operating System |
Windows Mobile 6.1/6.5 professional /Android 2.3 OS |
|
KVM |
JAVA MIDP 2.0 |
|
Default language |
English |
|
Package Contents |
|
Standard Packaging: Main Unit*1pc, Charger*1pc, USB Cable*1pc, battery*1pc, Case*1pc, Strap*1pc |
